side type breaker hammer operates using hydraulic power, providing strong impact force and outstanding durability.
Side Type Breaker Hammer operates using hydraulic power and is widely used in breaking various types of rock and concrete demolition tasks. LERB Machinery has optimized the internal structure of the breaker hammer with an integrated design that balances strength and service life, allowing it to maintain normal operation even under high-frequency impacts. This effectively reduces the failure rate and enhances construction efficiency. The Side Type Breaker Hammer offers advantages such as strong impact force, long service life, and low failure rates.
| Compact Range | Medium Range | |||||||||||
| Model | LYPS100 | LYPS200 | LYPS300 | LYPS350 | LYPS400 | LYPS430 | LYPS450 | LYPS900 | LYPS1600 | LYPS2000 | LYPS2200 | LYPS2200A |
| Carrier Weight (t) | 0.8-2.5 | 1.2-3.0 | 2.5-4.5 | 3.0-5.5 | 4-7 | 6-9 | 7-14 | 10-15 | 15-18 | 18-26 | 18-26 | 18-26 |
| Operating Weight (kg) | 77 | 90 | 132 | 198 | 275 | 418 | 561 | 842 | 1381 | 1609 | 1950 | 1950 |
| Oil Flow (L/min) | 15-30 | 20-40 | 25-50 | 30-60 | 40-70 | 50-90 | 60-100 | 80-110 | 90-120 | 100-150 | 120-180 | 120-180 |
| Operating Pressure (bar) | 150 | 150 | 150 | 150 | 170 | 180 | 190 | 200 | 210 | 210-230 | 210-230 | 210-230 |
| Relief Pressure (bar) | 90-120 | 90-120 | 90-120 | 100-130 | 110-140 | 120-150 | 130-160 | 150-170 | 150-170 | 160-180 | 160-180 | 160-180 |
| Impact Energy (J) | 203 | 271 | 406 | 542 | 677 | 1017 | 1355 | 2033 | 2711 | 3423 | 4067 | 4067 |
| Impact Rate (bpm) | 800-1400 | 700-1200 | 600-1100 | 500-1000 | 500-900 | 400-800 | 400-800 | 350-700 | 350-650 | 350-600 | 350-500 | 350-500 |
| Hose Size (inch) | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 3/4 | 3/4 | 1 | 1 | 1 | 1 |
| Noise Level (dB) | 106 | 107 | 109 | 117 | 109 | 115 | 112 | 114 | 115 | 120 | 118 | 118 |
| Chisel Dia. (mm) | 40 | 45 | 53 | 60 | 68 | 75 | 85 | 100 | 125 | 135 | 140 | 140 |
| Model | LYPS3000 | LYPS3200 | LYPS3500 | LYPS3500F | LYPS4500 | LYPS3000G | LYPS4000G | LYPS185 | LYPS195 | LYPS195P | LYPS200 | LYPS205 | LYPS210 | LYPS220 |
| Carrier Weight (t) | 25-30 | 28-35 | 30-40 | 30-40 | 35-40 | 25-33 | 35-45 | 35-45 | 40-55 | 50-55 | 50-70 | 50-70 | 60-80 | 70-80 |
| Operating Weight (kg) | 2350 | 2655 | 2735 | 3289 | 4167 | 2462 | 3001 | 4376 | 5039 | 5374 | 6205 | 6375 | 6683 | 7378 |
| Oil Flow (L/min) | 150-210 | 180-240 | 200-260 | 200-260 | 210-290 | 175-220 | 200-250 | 220-290 | 240-290 | 260-280 | 260-300 | 260-300 | 300-350 | 320-350 |
| Operating Pressure (bar) | 240-250 | 240-260 | 240-260 | 240-260 | 260-280 | 210 | 210 | 290-300 | 300-310 | 300-310 | 300-310 | 300-310 | 310-330 | 310-330 |
| Relief Pressure (bar) | 160-180 | 180-200 | 180-200 | 180-200 | 180-200 | 160-180 | 160-180 | 220-280 | 220-280 | 260-280 | 220-280 | 260-280 | 280-320 | 280-320 |
| Impact Energy (J) | 5423 | 6779 | 8812 | 10846 | 12202 | 5193 | 10388 | 14302 | 17088 | 19322 | 21360 | 23543 | 25632 | 27057 |
| Impact Rate (bpm) | 300-450 | 300-450 | 250-400 | 250-350 | 250-350 | 300-450 | 300-400 | 200-250 | 180-200 | 160-200 | 150-200 | 150-200 | 150-200 | 120-180 |
| Hose Size (inch) | 1 | 1-1/4 | 1-1/4 | 1-1/4 | 1-1/4 | 1 | 1-1/4 | 1-1/4 | 1-1/4 | 1-1/4 | 1-1/4 | 1-1/4 | 1-1/4 | 1-1/4 |
| Noise Level (dB) | 120 | 123 | 123 | 124 | 125 | 120 | 123 | 125 | 125 | 125 | 125 | 125 | 125 | 125 |
| Chisel Dia. (mm) | 150 | 155 | 165 | 165 | 175 | 150 | 160 | 185 | 195 | 195 | 200 | 205 | 210 | 220 |
The Side Type Breaker Hammer designed, developed, and produced by LERB Machinery operates using hydraulic power and offers advantages such as high stability, good safety, strong impact force, and long service life. Through in-depth market research and by listening to user needs, we have conducted extensive optimizations on the internal structure and performance of the breaker hammer, ensuring exceptional performance in breaking various types of rock and in concrete demolition tasks. Its integrated design significantly reduces equipment failure rates while effectively enhancing construction efficiency. LERB Machinery boasts a production base of 18,000 square meters, over 120 CNC machine tools and testing equipment, and more than 80 patents, ensuring consistent product quality and durability.
