What is PL-2000LQ Integrated Rock Drill and Splitter Machine?
LERB Machinery discovered through in-depth market and user research that users prefer more efficient and safer operations for breaking hard rock. In response to user needs, we at LERB Machinery designed and developed the PL-2000LQ integrated rock drill machine and splitter machine. This attachment can be installed on excavators weighing between 48 to 65 tons to handle various types of hard rock.
PL-2000LQ Integrated Rock Drill and Splitter Machine Specifications
Product Specifications| Total Weight | 7.8T |
| Overall Length | 5200mm |
| Overall Width | 1700mm |
| Overall Height | 2000mm |
| Excavator Requirements | 36-52 ton |
Power Head| Input Pressure | 205bar |
| Input Flow | 190L/min |
| Swing Torque | 3483Nm |
| Swing Speed | 70rpm |
| Borehole Diameter | Ø152mm |
Rock Splitter| Splitting Depth | 1500mm |
| Splitting Force (Two-Stage Pressure-Boosted) | 25000T |
| Rotation Angle | 120° |
| Feed Beam |
| Max. Thrust Force of Rock Drill | 40kN |
| Max. Splitter Retraction Force | 80kN |
| Swing Unit |
| Swing Force | 80kN |
| Swing Speed | 1rpm |
Remote Control System| Effective Range | 50m |
| Digital Output Channels | 30 |
| Analog Output Channels | 14 |
| Adjacent Channel Rejection | >50dB |
PL-2000LQ Integrated Rock Drill and Splitter Machine Advantages
- Suitable for various types of hard rock.
- Integrated design significantly enhances work efficiency when operating on hard rock.
- Non-explosive operation method greatly enhances safety and reliability.
- Digital control system enables precise drilling and rock breaking as needed.
- Rear-mounted electrical and hydraulic systems make inspection and maintenance easier.
PL-2000LQ Integrated Rock Drill and Splitter Machine Applications
- During the ore screening and processing, the PL-2000LQ integrated rock drill machine and splitter machine demonstrate excellent performance.
- It is suitable for precise drilling and splitting of various hard rocks such as marble and granite.
- PL-2000LQ integrated rock drill machine and splitter machine, combined with a digital control system, can process 1m³ of stone waste.
Why choose PL-2000LQ Integrated Rock Drill and Splitter Machine?
LERB Machinery is a specialized manufacturer of integrated hydraulic rock drill machines and splitter machines, with an 18,000 square meter production base, over 120 CNC machine tools and testing equipment, and more than 80 patents. The PL-2000LQ integrated rock drill machine and splitter machine is an attachment developed through in-depth market research and user understanding, designed for efficient drilling and splitting operations on different hard rocks when installed on 48 to 65-ton excavators. Certified by international standards such as ISO and CE, it utilizes a non-explosive operation method, combining the functions of a rock drill and splitter into one, and employs hydraulic technology for improved safety and stability.
